FloodGuard - Product Page
Safety & Flood Detection

FLOODGUARD STANDALONE UNIT

Protect your elevators with FloodGuard, providing instant water and oil detection for reliable elevator flood protection. Engineered for safety, versatility, and immediate alerts to prevent elevator pit flooding.

FloodGuard Standalone Device

The FloodGuard Standalone Unit is a reliable elevator flood protection system designed to detect water and oil in elevator pits. Featuring two solid-state fluid sensors, it delivers immediate audible and visual alarms to alert personnel. Optional integration with elevator control systems enables the unit to automatically move the elevator car to a safe floor during flood events, ensuring enhanced safety and preventing costly damage.

Key Advantages

Standalone Alarm
Functions independently if not connected to a controller.
Universal Flood Detection
Easily integrates with any elevator control system.
Dry Contact Terminals
Provides event signaling for alarms or elevator control.
Dual Fluid Sensors
Detects both water and oil with redundancy if needed.
Audible & Visual Alerts
100dB piezo alarm and light indicators for immediate detection.
NEMA 4 Enclosure
Conduit-friendly design for easy installation in pits.

Technical Specifications

Feature Details
ModelsSingle Sensor w/ Control Unit: ECIA045.00015273
Two Sensor w/ Control Unit: ECIA045.00015063
Input Power120VAC or 24VDC
Output ContactsTwo 5Amp Normally Open
Enclosure Type & DimensionsNEMA 4, 5L x 5W x 3D
Audible Alarm100dB Electric Piezo
Water/Oil SensorSolid State

Integrated Elevator Control Option

FloodGuard can be wired to elevator controls to signal the car to move to a safe floor in the event of a flood.
