This heavy-duty industrial limit switch features a zinc die-cast body engineered for precision, reliability, and long-term operation in demanding applications. Designed to meet EN 50041 standards, it offers galvanically separated contacts, positive opening of NC contacts, and flexible actuator positions for versatile mechanical and electrical control. Ideal for elevators, industrial machinery, conveyor systems, and automation equipment, this switch ensures safe and accurate operation in harsh environments.
Key Features
Zinc Die-Cast Body – Durable, corrosion-resistant construction
Increased Wiring Space – Simplifies installation and maintenance
Earth Grounding Surface – Same level as switching for safety
Interchangeable Contact Block – Easy replacement without downtime
Fine Adjustment – Precision screw for accurate switching point
Galvanically Separated Contacts – Electrical isolation for safety
Screw Terminals with Self-Lifting Clamps – Easy wiring
Positive Opening of NC Contacts – Reliable mechanical action
4 x 90° Actuator Positions – Flexible mounting and operation
Cable Entry Options – M20, PG13.5, and 1/2” NPT
EN 50041 Compliant – Meets industry standards
IP67 Rated – Dust-tight and waterproof for harsh environments
Technical Specifications
| Feature | Specification |
|---|
| Operating Speed | 0.05 mm – 2 m/sec |
| Operating Frequency | Mechanical: 120 ops/min; Electrical: 30 ops/min |
| Insulation Resistance | >100 MΩ @ 500V DC |
| Contact Resistance | <25 mΩ |
| Rated Current / Voltage | 10A / 600V AC (EN60947-5-1) |
| Electrical Rating | UL/cUL Listed (E216958) AC15 A600 / DC13 Q300 |
| Dielectric Strength | 1000 VAC for 1 min (non-continuous terminals); 2500 VAC for 1 min (terminal to ground) |
| Service Life | Mechanical: 10,000,000 ops; Electrical: 500,000 ops |
| Operating Temperature | -25~80℃ (-13~176°F), no icing |
| Humidity | <95% RH |
| Weight | 400–480 g (metal body) |
| Degree of Protection | IP67 |
